Compatible OS/Device
Miracast: Windows 11/10 and Android
Airplay: MacOS 11+ and iOS 13+
Google Cast: ChromeOS/Chrome 98+ and Android 8+
Audio & Video Specifications
Native protocol: Miracast, Airplay, Google Cast
Video: H.264 compression
Audio: LPCM 2.0
Resolution: Up to 4K302
Protection: HDCP 2.x3
Network Specifications
Ethernet: 1000Base-T RJ-45 LAN
Wireless (Miracast P2P1 & Wi-Fi Hotspot): 802.11ac 3×3 MIMO Dual-band 5GHz
Wireless (Infrastructure): 802.11ac 2×2 MIMO 2.4GHz and 5GHz (DFS)
BLE (Discovery): 2402-2480MHz
Authentication Protocol: IEEE 802.1x, WPA-PSK (TKIP), WPA2-PSK (AES), PEAP-MSCHAPv2, EAP-TLS
Hardware Specifications
Interfaces: 1 x HDMI® Output, 1 x RJ-45, 1 x USB 3.0 Host Type-A, 2 x USB 2.0 Host Type-A, 1 x Analog 3.5mm Audio, 1 x DC Power Jack
Power: Input 12VDC 3A, Consumption: 8.4W Typical 24.8W Peak
Temperature: Operating 0* – 40*C (32* – 104*F), Storage -20* – 85*C (-4* – 185*F)
Humidity: Operating 20-80% non-condensing, Storage 10-90% non-condensing
Dimensions
Size: W 8.66 in x D 5.66 in x H 1.99 in (220mm x 144mm x 50.5mm)
Weight: 1lb 4oz (471.74g)
Mounting Option
Wall mount. Magnetic mounting kit. VESA 75x75mm.
Regulatory and Compliance
Compliant Standards: FCC, RED, RoHS, UL
- Miracast P2P requires device with Wi-Fi and Intel 802.11 AC/AX Wi-Fi or equivalent is recommended.
- Display resolution and quality depend on Wi-Fi and or LAN network condition.
- Content protection only available for Miracast protocol.
