Mechanical
Dimension (W×H×D) (mm): 462×76×93 mm
Net Weight: 1.0kg
Gross Weight: 2.3kg
Environment
Operating Temperature: 0°C ~ 40°C
Storage Temperature: -20°C ~ 60°C
Operating Humidity: 10% ~ 90% RH Non-Condensing
Storage Humidity: 10% ~ 90% RH Non-Condensing
Software
Screen Sharing: InstaShare 2
File Management: AMS Files
UI: BenQ UNI Launcher
Account Management: AMS Account
Device Management: DMS
Camera Adjustment: Camera Settings
Video Conference: TeamViewer Meeting
Voice Assistant: Saffi
Browser: Firefox
Accessory
Remote Controller: x1
Adaptor / Plug: x5 (US/EU/AU/KR/UK)
HDMI cable: x1 (1.5m)
Type C to USB cable: x1 (3m)
Camera cover: x1
QSG: x1
Camera
Resolution: H.264/MJPG: 3840×2160 / 2560×1440 / 1920×1080 / 1280×720 / 1024x576 / 960×540 / 800×600 / 640×480 / 640×360 / 480×270 / 352×288 / 320×240 / 320×180 / 176×144 / 160×120 / 160×90
YUV2: 640×480 / 640×360 / 480×270 / 352×288 / 320×240 / 320×180 / 176×144 / 160×120 / 160×90
Field of view: DFOV: 120°
Focus: Fixed / 0.5m
Auto framing: Yes
Pixel: 12 MP
Digital Zoom: x5
Manual Adjustable Angle: ±15°
Pre-sets: 3
Microphone
Number: 6 - array
Pickup Distance: 8m
Voice Localization: Yes
Voice Optimisation: Beamforming / Noise reduction / Echo cancellation / Auto gain control
Speaker
Output Power: 8W x1
Automatic Level Control (ALC): Yes
System
Built-in OS: Android 9.0
Compatible OS: Win10 / Win8 / Win7 / Win XP / Linux OS /Mac OS / Chrome OS
Memory / Storage: 4GB / 16GB
Connectivity
IO Port: USB 2.0 (Type C, device port only) x1, USB 3.0 (Type A), HDMI out x1 RJ45 (10M/100M) x1, AUX (mic in / line out)
Ethernet LAN: 10 / 100 Mbps (Android)
Power
Power Requirements: 100-240Vac, 50/60Hz
Power Consumption (max/standby): 36W / <0.5W
