- Plug and click to instantly share your screen
- Side-by-side view of multiple screens
- Share entire screen, media files, or video feed
- Broadcast large display to connected devices
- No charging or batteries required
InstaShare Button
Colour: Silver
Wireless Transmission Frame Rate: Up to 60 fps depending on environment (1080P60/4K30P)
TX Button Input resolution: Up to 4K30P
Audio Rate: Stereo, Radio quality 16bits 48KHz
Wi-Fi Standard: IEEE 802.11ac 5GHz, 2T2R MIMO
Authentication protocol: Wi-Fi Standard
Wireless Security (Encryption): WPA2/3 Personal/WPA2 Enterprise Support AES-256
Wireless Coverage Reach: Max. 15 m (Between Button and IFP)
Cable: USB Type C
Power Supply: DC 5V±10%, Minimum 0.9A
Power Consumption: Max 4.5W Full Loading
Dimension (WxHxD): 67mm x 67mm x23.2mm
Temperature range: Operating: 0°C to +40°C (+32°F to +104°F) Storage: -10°C to +60°C (+14°F to +140°F)
Humidity range: Operating: 10% to 80% relative humidity Storage: 5% to 90% relative humidity (non-condensing)
Compatibility: 1. RM03 series (with USB Type-C)2. RP02, RE01, RM02K, RM02S, CP01K, CS01, SL02K series, and VC01A (with USB Type-C to USB Type-A adapter)
BenQ Wireless USB Dongle
Colour: Black
Wi-Fi Standard: 802.11 a/b/g/n/ac
Interface: USB 3.0
Wi-Fi band: Dual Band 2.4GHz / 5GHz
MU-MIMO: Yes
Wi-Fi Performance: 2.4 GHz Band: up to 400 Mbps
5 GHz Band: up to 867 Mbps
External Antenna: 2
Supported OS: AndroidWireless Coverage Reach
Max. 15 m (Between Dongle and IFP)
Security: WPA-PSK/WPA2-PSK WPA/WPA2/WEP
Power Supply: DC 5V, 0.9A (Maximum)
Dimension: L*H*W: 137 x 41 x 12 mm
Net Weight: 0.055kg
Temperature range:
Operation : 0℃~40℃
Storage : -40℃~70℃
Humidity range
Operation: 10%~90%Storage: 5%~90%
Compatibility: RM6503, RM7503, RM8603RP6502, RP7502, RP8602RE6501, RE7501, RE8601, RE9801RM6502K, RM7502K, RM8602KRM6502S, RM7502S, RM8602SCP6501K, CP8601KCS6501, CS7501, CS8601SL5502K, SL6502K, SL7502K, SL8502KST4302, ST5502, ST6502, ST7502, ST8602IL4301, IL5501BH2401, BH2401T, BH2801, BH2801N, BH3501, BH3501T, BH3801, BH3801D, BH3801NVC01A
BenQ InstaShare Dock
Colour: Black
Weight (Net): 420g
Dimension L*H*W: 150 x 85 x 106 mm
InstaShare Button Loading quantity: 4 pcs
Product material: PC+ABS & Aluminum alloy 6063 & Silica gel
