Part Number
Dimensions
Display Side Box
Height: 143 mm
Width: 143 mm
Depth: 34.5 mm
Table Side Box
Height: 143 mm
Width: 143 mm
Depth: 34.5 mm
Technical Specifications
Device Management: Logitech Sync device management
Ports and Interfaces:
Display Side (RX)HDMI 2.0 4K60 4:4:42x USB 2.0 Type AMicro USB Management InterfaceLogitech Extend PowerRJ45 to Table Side (TX)
Table Side (TX)Secured USB-C (from TX to user laptop)USB-C (optional USB-C power supply connection)RJ45 to Display Side (RX)
Mounting
VESA: 100 x 100 mm
Mounting Holes: 2 through-holes for mounting directly to the wall or table (mounting hardware included)
Power and Cables
Power supply: Auto-sensing
Operating Voltage/Power: 100-240V, 48V, 0.5A
Power Supply Dimensions: 73.5 mm x 53 mm x 35 mm
DC Cable: 1.5 m
USB-C to USB-C 3.2 Gen 1 Cable: 1.5 m
USB A to Micro USB Cable: 1 m
Environmental
Operating Temperature: 0° to 40° C
Storage Temperature: -25° to 70° C
Humidity: 10% to 90%
Security
File Based Encryption: NIST SHA-256 bits
Data Encryption: Public Key Hash
Firmware Update: Digital Signature
Sustainability
Made with recycled plastic: Logitech Extend plastic content: Minimum 40% post-consumer recycled material 1Excludes plastic in printed wiring assembly (PWA), cables, and packaging
Responsible Packaging: FSC™-certified paper packaging
Required
Meeting Room Equipment
Displays: HDMI 1.4 or higher
AV Devices: USB Type-A 2.0 or higher
Laptop Computers: USB Type-C port with DisplayPort Alt Mode
Compatible with
Conferencing Cameras: Rally Bar, Rally Bar Mini, Rally Bar Huddle, MeetUp, MeetUp 2, and more
Laptop Operating Systems: Windows 10, Windows 11, macOS (latest 2 versions)
